Energy Works On-Board Waterproof AC-DC 48V 20A Lithium Charger
Capable of handing anything the environment throws its way, this 48V Lithium-Iron Phosphate optimized charger is perfect for golf carts, or electric vehicles and equipment using 48V Lithium-Iron Phosphate batteries. Featuring an array of built in safety protections that constantly monitor all parameters. The 20A charging rate provides a fast, clean charge to your battery. The input and output cable both feature quick disconnects for easy installation or removal of charger or your battery.
Features
Marine-Grade material, designed for harsh conditions
LED status display with charging on/off button
Integrated cooling fan and heat sink for maximum heat dissipation
Smart-charging and battery monitoring
Built-in mounting brackets (can be mounted any direction)
IP67 Ingress Protection
Quick Disconnects on Input and Output Cables For Easy Removal
Specifications
Input Voltage: 105-120VAC 60hz (US Plug)
Output Voltage: 58.4VDC (LiFePO4)
Charging Current: 20A
Input Lead Length: 100 Inches / 8.3 Feet (removable cable w/ connector)
Output Lead Length: 70 Inches / 5.83 Feet (removable cable w/ connector)
Charger Dimensions: L x W x H; 11” x 3.5” x 8” (including mounting brackets and handle)
Weight: 9.5 Lbs.
Warranty
All chargers include a 2 year warranty against any manufacturer defects.
